Sony NEX-FS700R User Manual

11
Available Accessories
Simultaneous RAW/AVCHD recording
Simultaneous recording enables you to capture RAW to the outboard AXS-R5 while you record AVCHD files
onto the camera’s memory card as well as a clip-on HXR-FMU128 memory unit, sold separately. Using this
method, you can record three versions simultaneously. Since the recorded AVCHD files will have the same
time code as the RAW files, the AVCHD files can be used as proxies for off-line editing.
* AVCHD is not available during high-speed RAW recording.
* Recording duration is slightly different between RAW and AVCHD recording.
HD output for monitoring
HDMI/Component/Composite video outputs on the NEX-FS700R and the AUX OUT of the AXS-R5 can be
used for monitoring purposes. In order to achieve accurate monitoring of the wide dynamic range of RAW
recording, S-Log2 settings onto the picture profile of the NEX-FS700R.
* The gamma setting cannot be set individually for each video out/LCD panel/AVCHD recording.
* HD output or monitoring on FS700’s LCD are 16:9 mode only.
* AUX OUT of the AXS-R5 is disabled during 2K recording mode. (It is able to output 2K playback mode.)
SEL35F18
35mm F1.8 OSS
AXS-R5
2K/4K external 16bit RAW
recorder
SEL50F18
50mm F1.8 OSS
AXS-512S24
AXS Memory card, 512GB
BP-FL75
Olivine long-lasting battery
BC-L90
High speed battery charger for
BP-FL75 and V-Mount batteries
AXS-CR1
Card reader for AXS media
ACC-L1BP
AC Adaptor/Charger/Battery Kit
2NP-F970/B
Rechargeable Battery Pack
LCS-G1BP
Soft Carrying Case
LCS-BP1BP
Soft Carrying Case
HXR-FMU128
Flash Memory Unit
VCT-PG11RMB
Tripod with RM-1BP Remote Controller
RM-1BP
Remote Commander
SF-32UX
(32 GB, 16 GB, 8 GB)
SD/SDHC Memory Card
MS-PX64
(64 GB, 32 GB, 16 GB)
Memory Stick PRO-HG Duo™
Mirroring Memory Stick
MS-HX32B
(32 GB, 16 GB, 8 GB)
Memory Stick PRO-HG Duo™
SEL1018
10-18mm F4 OSS
HXR-IFR5
Interface unit for AXS-R5
Recommended E mount Lenses
RAW recording related products

Sony NEX-FS700R Specifications

General

Sensor type	CMOS
Total megapixels	11.6 MP
Optical sensor size	- \
Effective megapixels (image)	8.4 MP
Effective megapixels (movie)	8.3 MP
Optical zoom	- x
Image stabilizer	No
Camcorder media type	Memory card
Compatible memory cards	MS PRO, MS Pro-HG Duo, SD, SDHC, SDXC
Internal storage capacity	- GB
Outdoor white balance	Yes
Built-in light	-
Display diagonal	3.5 \
Display resolution	1920 x 480 pixels
Display aspect ratio	16:9
Display resolution (numeric)	91200 pixels
Viewfinder type	Not available
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 720 x 576, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 1080p, 480i, 576i, 720p
Video formats supported	AVC, AVCHD, H.264, MPEG2, MPEG4
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
Audio formats supported	LPCM
Microphone connectivity	XLR
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery type	NP-F770
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, AV, Component, USB

Weight and Dimensions

Depth	235.5 mm
Width	145 mm
Height	178.5 mm
Weight	1680 g
