Sony NEX-FS700R User Manual

5
Mount Adaptor LA-EA2 Compatible
The NEX-FS700R can attach A-mount lens via A-mount to E-mount adaptor
LA-EA2. Thanks to Translucent Mirror Technology on LA-EA2, auto focus
and one push auto iris functions are available during motion picture
shooting with most of A-mount lenses
LA-EA2 mount adaptor
Third party adaptor
A-mount lenses
E-mount lenses
NEX-FS700R
Mount Adaptor LA-EA2
Translucent Mirror Technology
Translucent Mirror Technology delivers responsive
autofocus with A-mount lenses
Translucent mirror
An innovative translucent mirror simultaneously and
continuously transmits light from the lens to both the
CMOS image sensor and AF sensor.
AF sensor
Light from the mirror is continuously transmitted to
the precision TTL phase detection AF sensor for
instant focus lock-on, even with fast-moving subjects.

Sony NEX-FS700R Specifications

General

Sensor type	CMOS
Total megapixels	11.6 MP
Optical sensor size	- \
Effective megapixels (image)	8.4 MP
Effective megapixels (movie)	8.3 MP
Optical zoom	- x
Image stabilizer	No
Camcorder media type	Memory card
Compatible memory cards	MS PRO, MS Pro-HG Duo, SD, SDHC, SDXC
Internal storage capacity	- GB
Outdoor white balance	Yes
Built-in light	-
Display diagonal	3.5 \
Display resolution	1920 x 480 pixels
Display aspect ratio	16:9
Display resolution (numeric)	91200 pixels
Viewfinder type	Not available
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 720 x 576, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 1080p, 480i, 576i, 720p
Video formats supported	AVC, AVCHD, H.264, MPEG2, MPEG4
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
Audio formats supported	LPCM
Microphone connectivity	XLR
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery type	NP-F770
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, AV, Component, USB

Weight and Dimensions

Depth	235.5 mm
Width	145 mm
Height	178.5 mm
Weight	1680 g
