Sony PlayStation 5 Quick Start Guide

2
1
Place the console with the rear side facing up, and
then remove the screw hole cap.
2
Attach the screw hole cap to the bottom of the base.
3
Remove the screw from the bottom of the base.
3
2
4
Attach the base, and then secure with a screw. Use a
coin or similarly shaped object to tighten the screw.
Bottom of
base
Let's get started
1
Attach the base.
Always attach the base to the console, whether it's in the
vertical or horizontal position.
Place your console on a flat surface when attaching the
base.
You'll need to reconfigure the base for the position
of your console. Rotate the top and bottom part of
the base in opposite directions. Keep rotating until
you hear a "click".
For the vertical position
Hook
With the base attached
Make sure the hook is in the position
as illustrated below before attaching
the base to the console.

Sony PlayStation 5 Specifications

General

Product color	Black, White
Internal memory	16000 MB
Processor cores	8
Processor model	AMD Ryzen Zen 2
Graphics processor	AMD Radeon
Processor frequency	3.5 GHz
Internal memory type	GDDR6
Processor manufacturer	AMD
Graphics processor frequency	2230 MHz
Graphics processor performance	10.3 TFLOPS
Number of controllers supported (max)	2
Power supply	350 W
Package depth	174 mm
Package width	469 mm
Package height	426 mm
Recommended gender	Boy/Girl
Storage media	SSD
Built-in optical drive	Yes
Card reader integrated	No
Internal storage capacity	825 GB
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Cables included	HDMI, USB
Game controllers included	Gamepad
Number of gamepads included	1
USB 2.0 ports quantity	0
HD type	8K Ultra HD

Weight and Dimensions

Depth	260 mm
Width	390 mm
Height	104 mm
Weight	4500 g
