Sony PlayStation 5 Safety Guide

EN
13
Specifications
Design and specifications are subject to change without notice�
Depending on the software version in use, the console may operate dierently than
described in this manual�
PlayStation®5 console
Console with the disc drive
installed
Console without a disc drive
installed
Main Processor
Single-chip custom processor
CPU: x86-64-AMD Ryzen™ “Zen2”, 8 cores/16 threads
GPU: 10 TFLOPS, AMD Radeon™ RDNA-based graphics
engine
Memory GDDR6 16 GB
Storage 1 TB Custom SSD
*1 *2
Input/output
*3
USB Type-A port (SuperSpeed USB 10Gbps) ×2
USB Type-C® port (Hi-Speed USB)
USB Type-C® port (SuperSpeed USB 10Gbps)
Expansion connector (Key M)
Disc drive port
Networking
Ethernet (10BASE-T, 100BASE-TX, 1000BASE-T)
IEEE 802�11 a/b/g/n/ac/ax
Bluetooth® 5�1
AV output HDMI™ OUT port
*4
Electrical rating
100–240 V
3�55–1�5 A
50/60 Hz
Maximum rated power 350 W
External dimensions
(excluding projecting parts)
Approx� 358 × 96 × 216 mm
(14�1 × 3�8 × 8�5 in) (width ×
height × depth)
Approx� 358 × 80 × 216 mm
(14�1 × 3�1 × 8�5 in) (width ×
height × depth)
Mass
Approx� 3�2 kg (7�0 lb) Approx� 2�6 kg (5�7 lb)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
*1 SSD capacity calculated using base 10 mathematics (1 GB = 1,000,000,000 bytes)�
*2 A portion of the SSD capacity is reserved for use in connection with console administration,
maintenance, and additional options� This may occur upon installation of system software or other
software� As a result, the availability of SSD capacity may vary depending on the console, system
software version, or available options, and is not otherwise available for your use�
*3 Functionality of all connected devices is not guaranteed�
*4 Use the included HDMI cable�
End of life product recycling
The console is made of many materials that may be recycled� The controller contains a
lithium ion battery� Follow local regulations when disposing of the console�
Sony products can be recycled for free in the United States and Canada by dropping the
product o at a number of nationwide locations� Visit
www�sony�com/ecotrade for details�

Sony PlayStation 5 Specifications

General

Product color	Black, White
Internal memory	16000 MB
Processor cores	8
Processor model	AMD Ryzen Zen 2
Graphics processor	AMD Radeon
Processor frequency	3.5 GHz
Internal memory type	GDDR6
Processor manufacturer	AMD
Graphics processor frequency	2230 MHz
Graphics processor performance	10.3 TFLOPS
Number of controllers supported (max)	2
Power supply	350 W
Package depth	174 mm
Package width	469 mm
Package height	426 mm
Recommended gender	Boy/Girl
Storage media	SSD
Built-in optical drive	Yes
Card reader integrated	No
Internal storage capacity	825 GB
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Cables included	HDMI, USB
Game controllers included	Gamepad
Number of gamepads included	1
USB 2.0 ports quantity	0
HD type	8K Ultra HD

Weight and Dimensions

Depth	260 mm
Width	390 mm
Height	104 mm
Weight	4500 g
