SS-CT52/TS53/TS54/TS55/TS56W/WS53
SECTION 3
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PD JACK
When indicating parts by reference number,
please include the board name.
A-1174-756-A BUILT PD BOARD, COMPLETE
************************
< CAPACITOR >
C7301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7303 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C7304 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C7305 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C7306 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7307 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C7308 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C7309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C7311 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C7312 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C7313 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7314 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C7315 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7316 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C7317 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C7318 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C7319 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7320 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C7321 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7322 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7323 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C7324 1-117-681-11 ELECT CHIP 100uF 20% 16V
< CONNECTOR >
* CN7301 1-564-517-11 PLUG, CONNECTOR 2P
< DIODE >
D7301 8-719-058-49 DIODE PP508
D7302 8-719-058-49 DIODE PP508
D7303 8-719-058-49 DIODE PP508
D7304 8-719-058-49 DIODE PP508
< IC >
IC7301 8-753-208-23 IC CXA3668N-T4
IC7302 6-704-261-01 IC TK11225CMCL-G
< COIL >
L7301 1-412-006-31 INDUCTOR 10uH
L7302 1-412-006-31 INDUCTOR 10uH
L7303 1-412-006-31 INDUCTOR 10uH
L7304 1-412-006-31 INDUCTOR 10uH
L7305 1-469-152-11 FERRITE, EMI (SMD) (2012)
L7306 1-400-305-11 INDUCTOR 47uH
< TRANSISTOR >
Q7301 8-729-216-22 TRANSISTOR 2SA1162-G
Q7302 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R7301 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R7302 1-216-821-11 METAL CHIP 1K 5% 1/10W
R7303 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R7304 1-216-839-11 METAL CHIP 33K 5% 1/10W
R7305 1-216-821-11 METAL CHIP 1K 5% 1/10W
R7306 1-216-837-11 METAL CHIP 22K 5% 1/10W
R7307 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7308 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7309 1-216-821-11 METAL CHIP 1K 5% 1/10W
R7310 1-216-809-11 METAL CHIP 100 5% 1/10W
R7311 1-216-797-11 METAL CHIP 10 5% 1/10W
R7312 1-216-833-11 METAL CHIP 10K 5% 1/10W
************************************************************
PD JACK BOARD
*************
< CONNECTOR >
CN100 1-564-505-11 PLUG, CONNECTOR 2P
< JACK >
J100 1-818-633-11 JACK, PIN 1P (TA-WR4)
< RESISTOR >
R100 1-216-864-11 SHORT CHIP 0
************************************************************
MISCELLANEOUS
**************
SP1 1-826-200-13 SPEAKER (7X10cm)
************************************************************
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
BUILT PD
