– 17 –
r
SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
r
CAPACITORS
uF : µ F
r
COILS
uH : µ H
NOTE :
r
Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
r
-XX, -X mean standardized parts, so they may
have some difference from the original one.
r
RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
r
Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
When indicating parts by reference
number, please include the board.
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
< TRANSISTOR >
Q701 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R700 1-249-441-11 CARBON 100K 5% 1/4W
R701 1-249-419-11 CARBON 1.5K 5% 1/4W
R702 1-249-419-11 CARBON 1.5K 5% 1/4W
R705 1-247-895-00 CARBON 470K 5% 1/4W
R706 1-249-433-11 CARBON 22K 5% 1/4W
R707 1-249-417-11 CARBON 1K 5% 1/4W
! R708 1-249-401-11 CARBON 47 5% 1/4W F
R711 1-247-807-31 CARBON 100 5% 1/4W
R716 1-247-807-31 CARBON 100 5% 1/4W
R717 1-247-807-31 CARBON 100 5% 1/4W
R718 1-247-807-31 CARBON 100 5% 1/4W
R719 1-247-807-31 CARBON 100 5% 1/4W
R722 1-247-807-31 CARBON 100 5% 1/4W
R723 1-247-807-31 CARBON 100 5% 1/4W
R724 1-247-807-31 CARBON 100 5% 1/4W
R725 1-247-807-31 CARBON 100 5% 1/4W
R726 1-249-437-11 CARBON 47K 5% 1/4W
R727 1-249-437-11 CARBON 47K 5% 1/4W
R751 1-249-401-11 CARBON 47 5% 1/4W
R752 1-249-403-11 CARBON 68 5% 1/4W
R753 1-247-807-31 CARBON 100 5% 1/4W
R754 1-249-407-11 CARBON 150 5% 1/4W
R755 1-249-407-11 CARBON 150 5% 1/4W
R756 1-249-409-11 CARBON 220 5% 1/4W
R757 1-249-411-11 CARBON 330 5% 1/4W
R758 1-249-413-11 CARBON 470 5% 1/4W
R759 1-249-415-11 CARBON 680 5% 1/4W
R760 1-249-417-11 CARBON 1K 5% 1/4W
R761 1-249-401-11 CARBON 47 5% 1/4W
R762 1-249-403-11 CARBON 68 5% 1/4W
R763 1-247-807-31 CARBON 100 5% 1/4W
R764 1-249-407-11 CARBON 150 5% 1/4W
* A-4389-239-A DISPLAY BOARD, COMPLETE(US,CND)
* A-4389-244-A DISPLAY BOARD, COMPLETE(AEP,UK,G,IT)
* A-4389-246-A DISPLAY BOARD, COMPLETE(E,SP,EA,MY,CH)
************************
* 4-921-941-01 CUSHION (FL)
* 4-979-925-01 HOLDER (FL-D)
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-124-465-00 ELECT 0.47uF 20% 50V
C703 1-162-306-11 CERAMIC 0.01uF 30% 16V
C704 1-162-306-11 CERAMIC 0.01uF 30% 16V
C705 1-104-905-11 CAPACITOR 0.22F 5.5V
C708 1-126-157-11 ELECT 10uF 20% 16V
C709 1-162-306-11 CERAMIC 0.01uF 30% 16V
C710 1-***-***-** CERAMIC 27PF
C711 1-***-***-** CERAMIC 27PF
C712 1-104-664-11 ELECT 47uF 20% 16V
C713 1-126-965-11 ELECT 22uF 20% 50V
< CONNECTOR >
CNJ701 1-774-342-11 PLUG, CONNECTOR (PC BOARD) 14P
CNP702 1-750-195-11 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D701 8-719-987-63 DIODE 1N4148M
D702 8-719-987-63 DIODE 1N4148M
D703 8-719-987-63 DIODE 1N4148M
D704 8-719-987-63 DIODE 1N4148M
< INDICATOR TUBE >
FL701 1-517-516-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC701 8-759-380-14 IC uPD78042AGF-078-3B9
IC702 8-749-923-43 IC GP1U57XB
DISPLAY
SECTION 6
ELECTRICAL PARTS LIST
r
Abbreviation
CND : Canadian SP : Singapore
AUS : Australian G : German
EA : Saudi Arabia IT : Italian
MY : Malaysia CH : Chinese
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
