6 (GB)
Design and specifications are subject to change without
notice.
Step 3:
Safety measures to
prevent toppling over
WARNING
Be sure to take measures to prevent the TV Stand from
toppling over, and causing possible injury and damage.
There is a hole to allow you to take measures to prevent
the TV Stand from toppling over, as shown in the
illustration below.
For details on the procedure, refer to the instruction
manual supplied with the TV.
Specifications
SU-52HX1 SU-46HX1
Dimensions:
mm (inches)
A
410
(16 1/4)
410
(16 1/4)
B
125
(5)
140
(5 5/8)
C
225
(8 7/8)
190
(7 1/2)
D
1,263
(49 3/4)
1,124
(44 3/8)
E
0°
812.8
(32)
732.8
(28 7/8)
6°
808.8
(31 7/8)
729.2
(28 3/4)
F
45
(1 13/16)
45
(1 13/16)
G
350
(13 7/8)
330
(13)
Stand Weight: 9.6 kg
(21.2 lb)
8.8 kg
(19.4 lb)
