60
Chapter 3 Appendix
Specifications
Signal
Pin Number
Pin Number
Signal
Connection Cable Specifications for Color Temperature Probes
Special cables are required to connect color
temperature probes other than the Sony BKM-14L to
the monitor.
The following diagrams show specifications and pin
assignments for the required cables.
Connection cable for Graseby SLS 9400 probe
Modular connector Mini DIN 8-pin connector
(male)
N.C.
GND
RXD
TXD
GND
N.C.
1
2
3
4
5
6
H SYNC
V SYNC
RTS
GND
N.C.
TXD
+5V
RXD
1
2
3
4
5
6
7
8
16
1
2
3
6
8
5
Accessories Supplied
AC power cord (1)
Cord stopper (1)
Tally plate (1)
Fuse (1)
Operation manual (1)
Design and specifications are subject to change
without notice.
