4-1. Replacing the CPU
I. How to remove the CPU.
1. Rotatethelockwithaat-bladescrewdrivertowardtheunlockposition,showninthegure.
2. RemovetheCPU.
lock position
unlock position
2
CPU
CPU socket
1
II. How to install the CPU
1. AlignthemarksontheCPUandtheCPUsocket.GentlyinsertCPUmakingsuretheCPUpins
areinsertedintotheholes.
2. Makesurebothcornersareseatedcorrectly,androtatethescrewdriver(athead)towardsthe
lockposition.
unlock position
lock position
mark
mark
CPU socket
1
CPU
2
Note:MakesuretheCPUislockedproperlytopreventdamageoroperationfailure.
