WM-D6C/TC-D6C
AUTO OFF LED
2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-3060-814-A AUTO OFF BOARD, COMPLETE
************************
* 3-308-430-01 RETAINER, REFLECTOR, PHOTO
< CAPACITOR >
C618 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C701 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C702 1-104-852-11 TANTALUM CHIP 22uF 20% 10V
C703 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C704 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C705 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C706 1-104-913-11 TANTALUM CHIP 10uF 20% 16V
< DIODE >
D701 8-719-801-78 DIODE 1S2837-T1
< IC >
IC701 8-759-958-14 IC MSM58141RS
< PHOTO REFLECTOR >
PH701 8-749-920-99 PHOTO REFLECTOR GP2S22AB
< TRANSISTOR >
Q701 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q702 8-729-120-28 TRANSISTOR 2SC1623-T1L6
Q703 8-729-420-50 TRANSISTOR UN5215- (TX)
Q704 8-729-420-50 TRANSISTOR UN5215- (TX)
< RESISTOR >
R701 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R702 1-216-109-00 METAL CHIP 330K 5% 1/10W
R703 1-216-845-11 METAL CHIP 100K 5% 1/16W
R704 1-216-103-00 METAL CHIP 180K 5% 1/10W
R705 1-216-103-00 METAL CHIP 180K 5% 1/10W
R706 1-216-841-11 METAL CHIP 47K 5% 1/16W
R708 1-216-837-11 METAL CHIP 22K 5% 1/16W
R710 1-216-847-11 METAL CHIP 150K 5% 1/16W
R711 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R712 1-216-845-11 METAL CHIP 100K 5% 1/16W
R713 1-216-857-11 METAL CHIP 1M 5% 1/16W
R715 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R716 1-216-812-11 METAL CHIP 180 5% 1/16W
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
< VIBRATOR >
X701 1-527-957-00 OSCILLATOR, CRYSTAL (34.7kHz)
**************************************************************
A-3060-816-A LED BOARD, COMPLETE
********************
* 3-305-888-00 RETAINER
3-305-897-00 HOLDER, LED
3-557-575-00 SPRING, COMPRESSION
3-831-441-99 SPACER (US)
4-017-441-01 CUSHION (B)
7-627-451-38 SCREW, PRECISION +K 1.4X2
< CAPACITOR >
C801 1-126-193-11 ELECT 1uF 20% 50V
C802 1-126-603-11 ELECT CHIP 4.7uF 20% 35V
C803 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C804 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
< LED >
D801 8-719-915-54 LED GL-9PR10 (LEVEL INDICATOR)
D802 8-719-915-54 LED GL-9PR10 (LEVEL INDICATOR)
D803 8-719-915-54 LED GL-9PR10 (LEVEL INDICATOR)
D804 8-719-915-54 LED GL-9PR10 (LEVEL INDICATOR)
D805 8-719-915-54 LED GL-9PR10 (LEVEL INDICATOR)
< IC >
IC801 8-752-060-72 IC CX10043-T4
< TRANSISTOR >
Q801 8-729-120-28 TRANSISTOR 2SC1623-T1L6
< RESISTOR >
R801 1-216-833-11 METAL CHIP 10K 5% 1/16W
R802 1-216-833-11 METAL CHIP 10K 5% 1/16W
R804 1-216-845-11 METAL CHIP 100K 5% 1/16W
R805 1-216-833-11 METAL CHIP 10K 5% 1/16W
R806 1-216-845-11 METAL CHIP 100K 5% 1/16W
R807 1-216-833-11 METAL CHIP 10K 5% 1/16W
R808 1-216-075-00 METAL CHIP 12K 5% 1/10W
R809 1-216-842-11 METAL CHIP 56K 5% 1/16W
R810 1-216-093-11 RES-CHIP 68K 5% 1/10W
