– 10 –
1
three connectors
(CNP103, 105, 205)
4
two screws
(B4
×
14)
5
bracket (TR)
6
four screws
(B3
×
10)
7
four screws
(B3
×
4)
2
two screws
(BV M3
×
12)
3
two spacers
7
four screws
(B3
×
4)
4
two screws
(B4
×
14)
5
bracket (TR)
1
connector
(CNP204)
8
two screws
(B3
×
8)
9
AMP board
AMP BOARD
