Sony Xperia S User Manual

To attach the back cover
1
Place the back cover over the back of the phone, then fit it into the slots.
2
Slide the cover towards the bottom end of the phone. You hear a sound when the
back cover locks into place.
Turning the phone on and off
To turn on the phone
1
Press and hold down the power key on the top of the phone until the phone
vibrates.
2
If your screen goes dark, briefly press the power key
to activate the screen.
3
To unlock the screen, drag to the right across the screen.
4
Enter your SIM card PIN when requested, and select OK.
Your SIM card PIN is initially supplied by your network operator, but you can change it later
from the Settings menu. To correct a mistake made while entering your SIM card PIN, tap
.
It may take a while for the phone to start up.
To turn off the phone
1
Press and hold down the power key
until the options menu opens.
2
In the options menu, tap Power off.
3
Tap OK.
It may take a while for the phone to shut down.
Screen lock
When your phone is on and left idle for a set period of time, the screen darkens to save
battery power, and locks automatically. This lock prevents unwanted actions on the
touchscreen when you are not using it. On the lockscreen, you can still view notifications,
for example, notifications of missed calls and messages that arrived since the phone was
last locked. You can also control the playback of audio tracks without unlocking the
screen.
To activate the screen
•
Briefly press the power key
.
10
This is an Internet version of this publication. © Print only for private use.

Sony Xperia S Specifications

General

Processor	Dual-core 1.5 GHz Scorpion
RAM	1 GB
Internal Storage	32 GB
Rear Camera	12 MP, f/2.4, autofocus, LED flash
Front Camera	1.3 MP
Battery	Non-removable Li-Ion 1750 mAh battery
Operating System	Android 2.3 (Gingerbread), upgradable to 4.1 (Jelly Bean)
Dimensions	128 x 64 x 10.6 mm
Weight	144 g
Network	GSM / HSPA
Announced	2012, January
Status	Discontinued
Technology	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 850 / 900 / 1900 / 2100
Speed	HSPA 14.4/5.76 Mbps
GPRS	Yes
EDGE	Yes
SIM	Mini-SIM
Protection	Scratch-resistant glass
Chipset	Qualcomm MSM8260 Snapdragon S3
GPU	Adreno 220
Card slot	No
Video	1080p@30fps
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 b/g/n, DLNA, hotspot
Bluetooth	2.1, A2DP, EDR
GPS	Yes, with A-GPS
NFC	Yes
Radio	Stereo FM radio, RDS
Sensors	Accelerometer, gyro, proximity, compass
Messaging	SMS(threaded view), MMS, Email, IM, Push Email
Browser	HTML5
Java	Yes, via Java MIDP emulator
Talk time	Up to 7 h 30 min (2G) / Up to 8 h 30 min (3G)
Display	4.3 inches
Colors	Black, White
Multitouch	Yes
Features	Geo-tagging, touch focus, face detection
USB	microUSB 2.0
Stand-by	Up to 420 h (2G) / Up to 420 h (3G)
