EN
3
AR8020T Telemetry Receiver
The Spektrum
™
AR8020T receiver
is a full range telemetry receiver
featuring DSM
®
technology. It is
compatible with all Spektrum
™
aircraft radios that support DSM2
®
and DSMX
®
technology.
Perform the failsafe setup for
the AR8020T receiver through a
compatible Spektrum Transmitter with Forward Programming. The Spektrum
PC Programmer can be used for firmware updates.
SPECIFICATIONS AR8020T
Type DSM2/DSMX 8 CH Telemetry Receiver
Application Air
Channels 8
Receivers 1
Remote Receiver
(not included)
SRXL2
™
Remote Receiver Optional (SPM9747 or
SPM4651T)
Modulation DSM2/DSMX
Data Flight Log
Compatible
No
Telemetry Integrated
Bind Method Bind Button
Failsafe Yes
Band 2.4GHz
Dimensions (LxWxH) 49 x 30 x 15mm
Weight 16g
Input Voltage 3.5–9V
Resolution 2048
Antenna Length 155mm and 186mm
Bind Button
Smart Port
XBUS Port
SRXL2 Port
Voltage Sensor Port
To Next Page
