PLATE COMPACTOR
19
PARTS LIST
No. Description Q'ty
1 Lifting Frame Weldment 1
2 Washer 12 4
3 Spring Washer 12 4
4 Bolt M12x35 4
5 Bolt M8x55 2
6 Hexagon Nut M8 2
7 Engine Base Weldment 1
8 Nut M8 1
9 Big Washer 8 2
10 Wheel Kit Holder 1
11 Bolt M8x40 1
12 Handle Shock Absorber 2
13 Nut M10 2
14 Engine 1
15 Clutch Pulley 1
16 Washer 20 1
17 Key 5x45 1
18 Engine Pulley Pressing Plate 1
19 Washer 8 1
20 Bolt M8x25 1
21 Nut M8 4
22 Washer 8 4
23
Engine Mounting Plate
Weldment
2
24 Belt Guard 1
25 Screw M8x25 2
26 Washer 8 2
27 Washer 8 2
28 Belt B29 1
29 Bearing 6407 2
30 Eccentric Shaft 1
31 Key C8x20 1
32 Exciter Pulley 1
33 Exciter Pulley Pressing Plate 1
34 Washer 8 1
No. Description Q'ty
35 Bolt M8x25 1
36 Exciter Housing 1
37 Oil Seal FB30x42x6F 1
38 Bearing Cover - Left 1
39 Exciter Housing Gasket 2
40 Bearing Cover - Right 1
41 Air Plug Screw 1
42 Sealing Washer 14 2
43 Bolt Plug M14x1.5 1
44 Screw M16x45 6
45 Spring Washer 16 6
46 Flat Washer 16 6
47 Bolt M6x20 12
48 Base Plate Weldment 1
49 Nut M12 4
50 Spring Washer 12 8
51 Flat Washer 12 8
52 Shock Absorbing Support 4
53 Nut M12 4
54 Upper Handle U-Tube 1
55 Lower Handle Tube 1
56 Button-headed Bolt 2
57 Knob-handle 2
58 Small Bushing 2
59 Ruber Bushing 2
60 Nut M12 2
61 Washer 12 4
62 Bolt M12x60 2
63 Throttle Control 1
64 Oil Drain Hose 1
65 Handle Sleeve 1
66 Belt Cover 1
