STIEBEL ELTRON DHC 6 XG User Manual

STIEBEL ELTRON
11
4. Installation Instruction
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17
Description of the unit (Internal)
4.1 Detailed description
2. Thermostat
3. Copper Tank
4. Hot water connection
5. Cold water connection
7. Cable entry with seal
8. Terminal block for earth wire
9. ELCB
Fig 3
10. Connector to PCB control (Base)
11. Reed switch
13. ELCB reset button
14. ELCB test button
15. Power Light
16. Connector to PCB Control (Cover)
17. PCB Cover
