7. Set the catch (7:C) to the rear position so that it
can lock.
8. Grip the front edge of the deck and lift up until
the deck locks in the first locking position.
See fig. 8.
6.3 SERVICE POSITION
It is absolutely forbidden to start the
engine when the deck is in the service
position.
1. Set the deck to the cleaning position. See above.
2. Grip the front edge of the deck and lift up fur-
ther until the deck locks in the second locking
position. See fig. 9.
6.4 RESETTING
Two people are required to reset from the cleaning
and service position as follows:
1. Person 1 lifts the deck at the front edge so that
it releases from catch (7:C).
2. Person 2 sets the catch to the front position.
3. Person 1 carefully lowers the deck to the
ground.
4. Other connections are made according to the
relevant section under “3”.
6.5 CLEANING
The underside of the deck must be cleaned after
each use.
Set the deck in the cleaning position.
Clean the underside of the deck thoroughly. Use
water and a brush.
When the surfaces are completely dry and clean,
touch up the paintwork. Use durable paint intended
for metal outdoors.
7 MAINTENANCE
7.1 LUBRICATION
Lubricate all lubrication points according to the ta-
ble below.
The three cutting shafts (13:C) must be lubricated
every 100 operating hours as well as after each
clean.
Other lubrication points must be lubricated every
250 hours of operation.
Use a grease gun, filled with universal grease for
the grease nipples. Pump until grease protrudes.
The lubrication points are shown in fig. 13.
7.2 REPLACING BLADES (10:D)
Wear protective gloves when changing
blade(s) to avoid cutting yourself.
Check that the blades are always sharp.
This produces the best cutting results.
Always check the blade(s) after a collision. If the
blade system has been damaged, defective parts
should be replaced.
Always use genuine spare parts. Non-
genuine spare parts can entail a risk of
injury, even if they fit the machine.
Install the new blade with the punched
text facing down.
The deck has two right-hand rotating blades and
one left-hand rotating blade. Direction of rotation
is defined seen from above. The left-hand rotating
blade is marked with a sticker as below and must
be installed on the left-hand side of the deck. See
fig. 10.
Tightening torque: 45 Nm.
7.3 LATERAL INCLINATION
After prolonged use and joint wear, the inclination
of the cutting deck requires adjustment.
Adjust as follows:
1. Disconnect the deck from the machine.
2. Place the deck on a flat surface and position a
50 mm board under the cutting deck (equal tres-
tle height on each side).
3.Connect the hoses for cutting height adjustment
to each other so that the cutting deck rests on the
board.
4. If the deck's lateral inclination is incorrect one
of the wheels will be suspended in the air and
the other will rest on the ground.
Piece Lubrication nipples /
action
Fig.
Bearings, belt ten-
sioner
2 lubrication nipples 13:A
Bearings for the rear
ejector hatches and
hydraulic cylinders
Lubricate using an oil
can filled with univer-
sal oil.
13:B
Cutting shafts 3 lubrication nipples 13:C
Bearings, link
wheel
4 lubrication nipples 13:D
Links and bearings
on the right and left
sides
14 lubrication nipples. 13:E
