Specifications
Engine
The "Emission Compliance Period"
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category A = 300 hours, B = 125 hours,
C = 50 hours
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Extended = 300 hours,
Intermediate = 125 hours,
Moderate = 50 hours
STIHL single cylinder, two-stroke engine
009 009 L
Displacement: 36.6 cm
3
40.8 cm
3
(2.23 cu.in) (2.49 cu.in)
Bore: 36 mm 38 mm
(1.42 in) (1.50 in)
Stroke: 36 mm 36 mm
(1.42 in) (1.42 in)
Power output according
ISO 7293: 1.2 kW 1.5 kW
Max. engine
speed with bar
and chain: 10,500 r.p.m.
Ignition System
Type:
Electronic (breakerless) magneto ignition
Spark plug (suppressed):
Bosch WSR 6 F or NGK BPMR 7 A
Heat range 200
Electrode gap 0.5 mm (0.02 in)
Spark plug thread:
M 14x1.25; 9.5 mm (0.37 in) long
Fuel/Oil System
Carburetor:
All position diaphragm carburetor
with integral fuel pump
Air filter:
Large area felt mat
Fuel tank capacity:
0.29 l (0.61 US pt)
Fuel mix:
See chapter "Fuel"
Chain lubrication:
Fully automatic oil pump
Oil tank capacity:
0.23 l (0.49 US pt)
Weight
without bar and chain:
4.1 kg (9.0 lb)
Cutting Attachment
Recommended cutting attachments
for compliance with § 5.11 of ANSI
Standard B 175.1-2000
(see page 12 of this Manual):
STIHL reduced kickback bar
(with green label):
Rollomatic with sprocket nose
30, 35 or 40 cm (12, 14 or 16 in)
STIHL low kickback chain*
(with green label):
9.32 mm (3/8") Picco-Micro1 (63 PM1)
Chain sprocket:
6- or 7-tooth for 3/8" Picco pitch
Other cutting attachments available for
this powerhead are:
STIHL yellow-labeled chain:
Picco-Micro (63 RM)
Since new bar/chain combinations may
be developed after publication of this
Manual, ask your STIHL dealer for the
latest STIHL recommendations.
In order to comply with the kickback
performance requirements of § 5.11
of ANSI Standard B 175.1-2000,
do not use replacement saw chain
unless it has been designated as
meeting the ANSI § 5.11 requirements
on this specific powerhead, or has been
designated as "low kickback" saw chain*
in accordance with the ANSI B 175.1-
2000 standard.
* See definition of "low kickback chain"
on page 11 of this Manual.
47
