Stihl AL 1 User Manual

0458-967-8321-A
8
English 7 Transporting
► Insert the plug (5) in a convenient wall outlet (6).
The charger (2) runs a self test. The LED (3) glows green
for about 1 second and then red for about 1 second.
► Fit the connecting cable (4).
► Insert the battery (1) in the guides in the charger (2) and
press it home as far as stop.
The LED (3) glows or flashes green. The battery (2) is
being charged.
► If the LEDs (3) stop glowing: The battery is fully charged
and can be taken out of the charger (2).
► If the charger (2) is no longer required. Disconnect the
plug (5) from the wall outlet (6).
6.3 LED on Charger
The LED indicates the operating status of the charger or
faults. The LED can glow or flash green or red.
If the LED glows or flashes green, the battery is being
charged.
► If the LED glows or flashes red: Troubleshooting, @ 11.1.
There is a malfunction in charger or battery.
7.1 Transporting
► Disconnect the plug from the wall outlet.
► Remove the battery.
► Wind up the connecting cable and attach it to the charger.
► Transporting the charger in a vehicle: Secure the charger
with lashing straps, belts or a net to prevent it turning over
and moving.
8.1 Storing the Charger
► Disconnect the plug from the wall outlet.
► Remove the battery.
► Wind up the connecting cable and attach it to the charger.
► Observe the following points when storing the charger:
– Charger is out of the reach of children.
– Charger is clean and dry.
– Charger is in an enclosed space.
– Charger is stored separately, away from the battery.
– Charger is not hanging from the connecting cable.
– Charger is in a temperature range between - 20°C and
+ 60°C.
9.1 Cleaning the Charger
► Disconnect the plug from the wall outlet.
7 Transporting
2
0000-GXX-8803-A0
3
4
5
6
1
8Storing
9Cleaning
0000-GXX-8804-A0
1
2

Stihl AL 1 Specifications

General

Brand	Stihl
Model	AL 1
Category	Battery Charger
Language	English
