Stihl BR 800 User Manual

BR 800, BR 800 X
English
30
1 Straight Nozzle (BR 800 C)
2 Blower Tube (BR 800 C)
3 Union Nut (BR 800 C)
4 Throttle Trigger
5 Setting Lever
6 Control Handle
7 Quick-Release Clamp
8 Pleated Hose
9 Harness
10 Backplate
11 Intake Screen
12 Air Filter Cover
13 Fuel Filler Cap
14 Base Plate
15 Starter Grip (BR 800 C)
16 Straight Nozzle (BR 800 X)
17 Blower Tube (BR 800 X)
18 Carburetor Adjusting Screws
19 Choke Knob
20 Manual Fuel Pump
21 Spark Plug Boot
22 Fuel Tank
23 Muffler (with Spark Arresting
Screen)
24 Spacer
25 Starter Grip (BR 800 X)
# Serial Number
Main Parts
1 2
16
17
3 4
5
6
9
10
11
12
13
1415
21
25
22
23
#
8
20
19
18
24
7
0000-GXX-6267-A0

Stihl BR 800 Specifications

General

Type	Backpack blower
Airflow	2025 m³/h
Suction mode	-
Product color	Black, Orange, White
Airspeed (max)	349.2 km/h
Power source	Gasoline
Sound power level	112 dB
Sound pressure level	104 dB

Weight and Dimensions

Weight	11700 g
