Stihl FS 311 User Manual

FS 311
English
21
Swinging handlebar into transport
position
N Loosen the wing screw (3) and
unscrew it until the handlebar (7)
can be rotated.
N Rotate the handlebar 90°
counterclockwise and then swing
the handles down.
N Tighten down the wing screw (3)
firmly.
Swinging handlebar into working
position
N Reverse the sequence described
above to swing the handles up and
turn the handlebar clockwise.
It may be necessary to correct the
adjustment of the throttle cable after
assembling the machine or after a
prolonged period of operation.
Adjust the throttle cable only when the
unit is completely and properly
assembled.
N Set the throttle trigger to the full
throttle position.
N Carefully rotate the screw in the
throttle trigger in the direction of the
arrow until you feel initial resistance.
Then rotate it another half turn in the
same direction.
Use the Right Deflector
WARNING
Deflector (1) is approved for mowing
heads only and must therefore be
mounted before fitting a mowing head.
WARNING
Deflector (2) is approved for grass
cutting blades and brush knives only and
must therefore be mounted before fitting
a grass cutting blade or brush knife.
7
3
0000-GXX-0513-A0
Adjusting the Throttle Cable
002BA655 KN
Mounting the Deflector
1
002BA401 KN
2
002BA402 KN

Stihl FS 311 Specifications

General

Type	2-in-1 Brush cutter & String trimmer
Cordless	Yes
Head type	Blade
Handle type	U-type handle
Engine power	1.9 hp
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Rotational speed	8500 RPM
Number of strokes	4
Sound power level	110 dB
Fuel tank capacity	0.71 L
Engine displacement	36.3 cm³
Sound pressure level	99 dB
Cutting diameter (max)	480 mm
Power source	Gasoline

Weight and Dimensions

Length	1800 mm
Weight	7200 g
