Stihl HL 94 User Manual

HL 94
English
17
Preparations
WARNING
When fueling on a slope, always position
the machine so that the filler cap is
facing uphill.
N On level ground, position the
machine so that the filler cap is
facing up.
N Before fueling, clean the filler cap
and the area around it to ensure that
no dirt falls into the tank.
Always thoroughly shake the mixture in
the canister before fueling your
machine.
WARNING
To reduce the risk of fire and personal
injuries due to escaping fuel and vapor,
remove the fuel filler cap carefully so
that any excess pressure in the tank can
escape slowly. Use the proper seasonal
gasoline blend, i.e., winter blend in
winter, summer blend in summer.
Opening the screw cap
N Turn the cap counterclockwise until
it can be removed from the tank
opening.
N Remove the filler cap.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank.
Closing the screw cap
N Position cap.
N Turn the cap clockwise as far as it
will go and tighten it as securely as
possible by hand.
Angle Adjuster - 145°
The angle of th cutter bar can be
adjusted upwards in 4 stages from 0°
(straight) to 55°, and downwards in 7
stages from 0° to 90° (right angle facing
down). There are therefore 12 possible
working positions.
WARNING
To reduce the risk of injury, carry out the
adjustment only when the cutting blades
are at a standstill – engine at idle speed.
WARNING
The gearbox gets hot during operation.
To reduce the risk of burn injury, do not
touch the gearbox.
Fueling
0208BA019 KN
0208BA020 KN
0208BA021 KN
Adjusting the Cutter Bar
0000-GXX-1683-A0
145°
