KM 111 R, KM 131 R
English
25
KM 131 R
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Weight
Features
Users of this unit should carry out only
the maintenance operations described
in this manual. STIHL recommends that
other repair work be performed only by
authorized STIHL servicing dealers
using genuine STIHL replacement parts.
Genuine STIHL parts can be identified
by the STIHL part number, the
{ logo and, in some cases, by
the STIHL parts symbol K. The
symbol may appear alone on small
parts.
For repairs of any component of this
unit’s air emissions control system,
please refer to the air emissions
systems warranty in this manual.
Engine power to ISO
8893:
1.05 kW
(1.4 bhp)
at 7,500 rpm
Idle speed: 2,800 rpm
Cut-off speed (rated): 9,500 rpm
Valve clearance
Inlet valve: 0.10 mm
(0.004 in)
Exhaust valve: 0.10 mm
(0.004 in)
Displacement: 36.3 cc
(2.22 cu.in)
Bore: 43 mm (1.69 in)
Stroke: 25 mm (0.98 in)
Engine power to ISO
8893:
1.4 kW (1.9 bhp)
at 8,500 rpm
Idle speed: 2,800 rpm
Cut-off speed (rated): 9,500 rpm
Valve clearance
Inlet valve: 0.10 mm
(0.004 in)
Exhaust valve: 0.10 mm
(0.004 in)
Spark plug (resistor
type): NKG CMR 6H
Electrode gap: 0.5 mm (0.02 in)
Fuel tank capacity: 0.71 L (24 fl.oz)
dry, without
KombiTool: 4.4 kg (9.7 lbs)
R Loop handle
