0478-111-9949-A
49
English
19 Specifications
19.1 STIHL RM 2.1 R Lawn Mower
– Engine type:
– RM 2.1 R: STIHL EVC 200
– Displacement:
– RM 2.1 R: 139 cm³
– Power:
– RM 2.1 R: 2.1 kW (2.8 hp) at 2,800 rpm
– Speed:
– RM 2.1 R: 2,800 rpm
– Maximum fuel tank capacity: 900 cm³ (0.9 l)
– Weight:
– RM 2.1 R: 24 kg
– Cutting width:
– RM 2.1 R: 46 cm
19.2 Blade
– Minimum thickness a: 2.0 mm
– Minimum width b: 45 mm
– Sharpening angle c: 30°
19.3 Sound Values and Vibration Values
RM 2.1 R
The K value for the sound pressure level is 2 dB(A). The K
value for the sound power level is 1,4 dB(A). The K value for
the vibration values is 3,16 m/s².
– Sound pressure level L
pA
measured in accordance with
2006/42/EC: 79 dB(A)
– Sound power level L
wA
measured in accordance with
2000/14/EC: 91 dB(A)
– Vibration value a
hv
measured in accordance with
EN 12096, handlebar: 7,90 m/s²
For information on compliance with Employers' Vibration
Directive 2002/44/EC see www.stihl.com/vib.
19.4 REACH
REACH is an EC regulation and stands for the Registration,
Evaluation, Authorisation and Restriction of Chemical
substances.
For information on compliance with the REACH regulation
see www.stihl.com/reach.
20.1 Spare parts and accessories
STIHL recommends the use of original STIHL spare parts
and accessories.
Despite ongoing market observation, STIHL is unable to
judge the reliability, safety and suitability of other
manufacturers' spare parts and accessories; accordingly,
STIHL cannot warrant for the use of those parts.
Original STIHL spare parts and original STIHL accessories
are available from STIHL dealers.
20.2 Essential Spare Parts
STIHL assumes no liability for injury to people or damage to
property resulting from the use of unauthorised attachments
or spare parts.
– Blade: 6357 702 0102
– Blade fastening screw: 9008 319 9028
– Washer: 0000 702 6600
19 Specifications
20 Spare Parts and Accessories
These symbols indicate original STIHL spare
parts and original STIHL accessories.
