Stihl RMA 2 RT User Manual

0478 131 9939 A - EN
50
Langkampfen,
2018-01-02 (YYYY-MM-DD)
VIKING GmbH
Head of Design
18.2 STIHL charger AL
This charger has been manufactured and
brought into circulation in compliance with
the following directives:
2014/30/EU, 2014/35/EU, 2011/65/EU
The full EC Declaration of Conformity is
available from ANDREAS STIHL AG & Co.
KG.
ANDREAS STIHL AG & Co. KG
Badstraße 115
D-71336 Waiblingen
Germany
19.1 Lawn mower STIHL RMA 2.0 RT
19.2 STIHL AP battery
This symbol indicates the
number of cells and the energy
content according to the cell
manufacturer's specifications.
The available energy content is
lower in practice.
19.3 STIHL charger AL
Protection class II. The charger
housing features double
insulation to the mains supply.
For charging times, please refer to
www.stihl.com/charging-times.
19. Technical specifications
Serial number 6357
Permissible battery STIHL AP
Motor, design Electric motor
Engine type EC motor
Motor unit/battery MVP 850
Voltage 36 V
Power input 850 W
Protection class III
Type of protection IPX 1
Cutting device Cutter bars
Cutting width 46 cm
Speed of cutting utilities:
Normal mode 3150 rpm
Eco mode 2800 rpm
Cutter bar drive Permanent
Self-propulsion 1 gear
Drive speed 3,5 km/h
Cutting height 28 - 85 mm
Blade fastening
screw tightening
torque 60 - 65 Nm
Wheel diameter
(front) 200 mm
Wheel diameter
(rear) 200 mm
Length 140 cm
Width 50 cm
Height 105 cm
Weight 23 kg
Sound emissions:
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
87 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
74 dB(A)
Uncertainty K
pA
2dB(A)
Hand-arm vibrations:
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
1,40 m/sec
2
Uncertainty K
hw
0,70 m/sec
2
Measurement in accordance with
EN 20643
Battery technology Lithium ion
Voltage 36 V
Capacity in Ah See rating plate
Energy content in
Wh See rating plate
Weight in kg See rating plate
Permissible tempera-
ture range -10°C to +50°C
Rated voltage 220 - 240 V,
50 Hz
Nominal output See rating plate
Charge current See rating plate
Permissible tempera-
ture range See rating plate
Hand-arm vibrations:

Stihl RMA 2 RT Specifications

General

Brand	Stihl
Model	RMA 2 RT
Category	Lawn Mower
Language	English
