Stihl RMA 235 User Manual

0478-131-9541-A
16
English 9 Inserting and Removing the Activation Key
► Press locking lever (2).
Battery (3) is released.
► Remove battery (3).
► Close flap (1).
9.1 Inserting the Activation Key
► Open flap (1) as far as the stop and hold.
► Insert activation key (2) in key receptacle (3).
► Close flap (1).
9.2 Removing the Activation Key
► Open the flap as far as the stop and hold.
► Pull out the activation key.
► Close the flap.
► Keep the activation key out of the reach of children.
10.1 Activating and Deactivating the Blade
10.1.1 Activating the Blade
► Place the lawn mower on a level surface.
► Press locking button (1) with the right hand and hold.
► Pull control bar for mowing (2) with the left hand fully in the
direction of handlebar (3) and hold so the thumb encloses
handlebar (3).
The blade turns.
► Release locking button (1).
► Hold handlebar (3) and control bar for mowing (2) with the
right hand so the thumb encloses handlebar (3).
10.1.2 Deactivating the Blade
► Release the control bar for mowing.
► Wait until the blade is no longer turning.
► If the blade continues to turn: pull out the activation key,
remove the battery and consult a STIHL specialist dealer.
The lawn mower is defective.
9 Inserting and Removing the Activation
Key
10 Switching the Lawn Mower On and Off

Stihl RMA 235 Specifications

General

Type	Walk behind lawn mower
Cutting width	330 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Uncertainty K	0.9 m/s²
Housing material	Plastic
Number of wheels	4 wheel(s)
Rotational speed	3400 RPM
Maximum lawn area	- m²
Mulching function	-
Sound power level	89 dB
Handle(s) features	Foldable
Standard deviation	2 dB
Vibration emission	1.8 m/s²
Sound pressure level	87.9 dB
Maximum cutting height	60 mm
Minimum cutting height	25 mm
Grass collecting volume	30 L
Number of height positions	5
Power source	Battery
Power consumption (typical)	450 W

Weight and Dimensions

Weight	14000 g
