Sub-Zero 600 Series Service Manual

Component Access / Removal
600 Series
(Prior to #1810000)
7-2
#3756270 - Revision B - January, 2006
COMPONENT ACCESS AND REMOVAL
This section explains how to adjust, access and remove components. If different models have similar procedures,
they are grouped together under the appropriate heading. The models covered in the procedures are listed between
brackets after the heading.
This section is arranged as follows:
.............................................................................................................. Page:
• Primary Parts .................................................................................................................................................... 7-3
• Refrigerator Interior Cosmetic / Mechanical ...................................................................................................... 7-10
• Freezer Interior Cosmetic / Mechanical / Electrical ............................................................................................ 7-15
• Lower Compressor Area / Mechanical / Electrical .............................................................................................. 7-32
• Upper Compressor Area / Mechanical / Electrical .............................................................................................. 7-33
• Water Valve ........................................................................................................................................................ 7-35
• Sealed System .................................................................................................................................................. 7-36
An attempt has been made to arrange these procedures in such a way as to simulate which components would
need to be removed first in order to gain access to other components. When following a component removal proce-
dure, it may be necessary to reference another component removal procedure earlier in this section.
NOTE: Before continuing, please take note of the WARNINGS and CAUTIONS below.
• IF IT IS NECESSARY TO REMOVE A UNIT FROM ITS INSTALLATION, REMEMBER THAT THE UNIT
COULD TIP FORWARD WHEN PULLED FORWARD BEYOND THE ANTI-TIP COMPONENTS, RESULTING
IN SERIOUS INJURY OR DEATH. PULLING A UNIT FROM ITS INSTALLATION SHOULD ONLY BE PER-
FORMED BY AN AUTHORIZED SERVICE TECHNICIAN OR INSTALLER.
• TO AVOID ELECTRIC SHOCK, POWER TO THE UNIT MUST BE DISCONNECTED WHENEVER ACCESS-
ING AND/OR REMOVING COMPONENTS POWERED BY ELECTRICITY OR COMPONENTS NEAR OTHER
ELECTRICAL COMPONENTS. IF THE UNIT IS PLUGGED IN, BUT HAS NOT BEEN SWITCHED ON BY
PRESSING THE UNIT ON/OFF KEY, 115 VOLTS AC IS STILL PRESENT AT THE CONTROL BOARD.
• IF REMOVING A DOOR OR DRAWER FROM A UNIT, REMEMBER THAT DOORS AND DRAWERS ARE
HEAVY. IF THEY WERE TO FALL, THEY COULD CAUSE SERIOUS PERSONAL INJURY.
• If removing or disconnecting door closer assemblies, remember they are spring loaded and could recoil
quickly when released.
• If working in the compressor area, remember that compressor and tubing may be hot.
• If working on or around an evaporator or condenser, remember that evaporator and condenser fins are
sharp.
