TOP OF
ROUGH
OPENING
78
9
/16"*
(1995)
34
1
/2"*
(876)
14"(356)
13
/16"
(
21)
9
3
/4"
(248)
4"
(102)
80"*
(2032)
27"
(686)
24"
(610)
*
1
/2" (13)
+
_
ADJUSTMENT IN LEVELING LEGS
FRONT VIEW
SIDE VIEW
(
UNIT DIMENSION) (UNIT DIMENSION)
3
/8"
(10)
13
1
/4"
(337)
1
/2"
(13)
10
1
/4"
(260)
20
3
/8"
(518)
DOOR
MOUNTING
DETAIL
DRAWER
MOUNTING DETAIL
105˚
90˚
90˚ DOOR OPENING
DOOR/DRAWER
CLOSED
MAXIMUM DOOR OPENING
*
DOOR/DRAWER PANEL THICKNESS NOT INCLUDED – DIMENSION WILL VARY WITH INSTALLATION
DOOR/DRAWER
CLOSED
19
1
/2"*
(495)25
1
/2"*
(648)
24"
(610)
25
7
/8" (657)
4
5
/8"*(117)
TOP VIEW
Planning Information
Model 700TF(I)
2
Dimensions in parentheses are in
millimeters unless otherwise specified.
OVERALL DIMENSIONS
FEATURES
Tall freezer unit with upper cabinet freezer
and freezer storage drawers
Model 700TFI has automatic ice maker
Integrated design for "point-of-use" refriger-
ation anywhere in the home
Refrigeration system ensures the best food
storage and energy efficiency
Electronic digital controls are up front and
easy to use
Flat to the ceiling bright lighting in cabinet
and drawers
Adjustable spill-proof glass shelves
Door alarm will let you know with an audible
beeping if a door or drawer is left open
Top storage drawer has a removable divider
The exclusive dual action hinge has a built-in
90˚ door stop
Meets strict Department of Energy
requirements
UL approved for US and Canada
Two, five and twelve year residential
warranty – exclusions apply; warranty
information can be found on our website,
subzero.com
Dimensions ma
y vary by ±
1
/8" (3).
To Next Page
