Subaru ER12 User Manual

- 71 -
ITEM STD Limit
CONNECTING ROD
* Large end inner diameter
24000 - 24013
(09449 - 09454)
241
(09488)
* Clearance between large end and crank pin
0020 - 0046
(00008 - 00018)
02
(00079)
* Small end inner diameter
12010 - 12021
(04728 - 04733)
1208
(04756)
* Clearance between small end and piston pin
0010 - 0029
(00004 - 00011)
012
(00047)
* Large end side clearance
0100 - 0700
(00039 - 00276)
10
(00394)
CRANKSHAFT
* Crank pin outer diameter
23967 - 2398
(09436 - 09441)
2385
(09390)
* Journal outer diameter
D1
19988 - 11997
(07869 - 04723)
D2
21988 - 21997
(08657 - 08660)
D1
D2
Unit: mm (in)

Subaru ER12 Specifications
