MODEL
Type
Continuous Output
Maximum Output
Direction of Rotation
Lubricant
Oil Capacity
Fuel
Fuel Tank Capacity
Spark Plug
Starting System
Dry Weight
Specifications are subject to change without notice
Dimensions (L x W x H)
EH09-2D
Air-cooled,4-cycle,single-cylinder, horizontal shaft,OHV,gasoline engine
Bore x Stroke 51 x 42
Piston displacement 86
Compression ratio 8.7
1.5 / 3600
2.1 / 4200
Maximum torque 4.9 / 3600
Counter clockwise as viewed from PTO shaft side
4-stroke automotive detergent oil - SAE; #20,#30 or 10W-30
API service class; SE or higher (SG, SH or SJ is recommended)
Lubrication Splashing type
Valve arrangement Over Head Valve type
Cooling system Forced air cooling
0.3
Carburetor Horizontal draft,float type
Automotive unleaded gasoline
Fuel feed Gravity type
1.5
Method of ignition Flywheel magneto (solid state)
NGK : BMR4A (CHAMPION : RCJ14)
Recoil starter
Governor Centrifugal flyweight type
Air Cleaner system Semi wet type
9.9
249 x 299 x 380
mm
mL(cc)
kW / rpm
kW / rpm
N･m / rpm
liter
liter
kg
mm
9. SPECIFICATIONS
EH092_GB_EU2311 06.12.21 1:38 PM ページ9

Subaru EX21 Specifications

General

Displacement	211 cc
Lubrication System	Splash
Ignition System	Transistorized magneto
Starting System	Recoil
Compression Ratio	8.5:1
Fuel System	Carburetor
Engine Type	Air-cooled 4-stroke OHV
Maximum Torque	12.3 Nm / 2500 rpm
Fuel Tank Capacity	3.6 liters
Oil Capacity	0.6 liters
