14
Super A2SDi-TP8F/LN4F, A2SDi-16C-TP8F User's Manual
Connector Description
JSD1 SATA DOM Power Connector
JSMB1 PCH SMBus Header
JTGLED1 LAN5/LAN6 Acitivity LED Header
JTGLED2 LAN7/LAN8 Acitivity LED Header
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1 ~ LAN8
LAN1 - LAN4: GbE LAN (RJ45) Ports
LAN5 - LAN6: 10GBaseT LAN (RJ45) Ports
LAN7 - LAN8: 10G LAN (SFP+) Ports
(LAN5 - LAN8 not available on A2SDi-LN4F)
SLOT7 CPU PCI-E 3.0 x4 Slot
SRW1, SRW3, SRW4 M.2 Holding Screws
UID Unit ID Button
USB0/1 Back panel Universal Serial Bus (USB) 3.0 Ports
USB2/3, USB4/5 Front Accessible USB 2.0 Headers
VGA VGA Port
