Suzuki AY50 User Manual

AY50K1 K2/WRK1 K2 (’01 ’02-MODEL) 11-5
TRANSMISSION Unit: mm Except ratio
ITEM STANDARD LIMIT
Reduction ratio P-22 * Variable 2.768 – 1.005 ———
P-02, 39 Variable 2.768 – 0.871 ———
P-04,26,34,53 Variable 2.975 – 1.140 ———
Final reduction ratio P-02, 22, 39 14.960 (51/15 × 66/15) ———
P-04,26,34,53 13.812 (51/15 × 65/16) ———
Drive belt width P-02, 22, 39 16.9 15.9
P-04,26,34,53 18.4 17.4
Driven face spring free length 110 104.5
CARBURETOR
ITEM
SPECIFICATION
P-04, 26, 53 P-02
Carburetor type KEIHIN PWS14 ←
Bore size 14 mm ←
I.D. No. 35EE 35E2
Idle r/min. 1 900 ± 200 r/min. 1 700 ± 200 r/min.
Float height 5.1 ± 0.5 mm ←
Main jet (M.J.) #70 #60
Jet needle (J.N.) N4WA-3rd ←
Pilot jet (P.J.) #48 #45
Air screw (A.S.) 1¼ turns back 1
3
/
8
turns back
Throttle cable play 2 – 4 mm ←
ITEM
SPECIFICATION
P-22 P-34 P-39
Carburetor type KEIHIN PWS14 KEIHIN PWS12 ←
Bore size 14 mm 12 mm ←
I.D. No. 35EJ 35EG 35EB
Idle r/min. 1 900 ± 200 r/min. ← 1 700 ± 200 r/min.
Float height 5.1 ± 0.5 mm ←←
Main jet (M.J.) *#65 ← #55
Jet needle (J.N.) *N5GJ-3rd 6LQJ-5th N5GJ-3rd
Pilot jet (P.J.) *#40 #45 #35
Air screw (A.S.) *1
3
/
4
turns back 3 turns back
3
/
8
turn back
Throttle cable play 2 – 4 mm ←←

Suzuki AY50 Specifications

General

Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Brake	Drum
Ignition	CDI
Starting System	Electric and kick
Front Tire	120/70-12
Rear Tire	130/70-12
Length	1, 830 mm
Transmission	Automatic
Rear Suspension	Swingarm
