1 Starter motor relay fuse: 30 A
2 Ignition coil/Injector/Engine control module:
30 A
3 IAC fuse: 15 A
4 PTT switch fuse: 15 A
5 Fuel pump fuse: 15 A
6 Load fuse: 60 A
7 Main fuse: 60 A
8 Spare fuse: 60 A
9 Spare fuse: 30 A
0 Spare fuse: 15 A
A Spare fuse: 15 A
B Sub battery cable fuse: 15 A
NOTE:
Spare fuses 9 and 0 are provided for the back
of fuse box cover.
SPECIFICATIONS
Item DF115B DF140B
Engine Type 4 Stroke
Number of Cylinders 4
Bore and Stroke 86.0 × 88.0 mm (3.39 × 3.46 in)
Piston Displacement 2045 cm
3
(124.8 cu. in)
Maximum output 84.6 kW (115PS) 103.0 kW (140PS)
Full Throttle Operating Range 5000 – 6000
r/min. (min
–1
)
5700 – 6300
r/min. (min
–1
)
Ignition System Full-transistor
Engine Lubrication Trochoid pump pressure lubrication
Engine Oil Capacity 5.5 L (5.8/4.8 US/lmp. qt.)
Gear Oil Capacity 1.05 L (1.1/0.9 US/Imp. qt.)
Spark Plug NGK LKR6E
Spark Plug Gap 0.8 – 0.9 mm (0.031 – 0.039 in)
Valve Clearance (Lash) IN. : 0.23 – 0.27 mm (0.009 – 0.011 in)
EX.: 0.33 – 0.37 mm (0.013 – 0.015 in)
Fuel Type Alcohol-free unleaded gasoline
Minimum Fuel Octane Rating 91 (Research method)
