34
MANUAL TILTING
If you are unable to tilt the motor using the
“Power Trim and Tilt” because of an electrical
problem or some other problem, you can move
the motor manually. To tilt the motor up or
down, turn the manual release screw A two
turns counterclockwise, move the motor to the
desired position, then retighten the release
screw.
TILT LOCK LEVER
The tilt lock lever is provided so you can sup-
port the motor in a tilted position for non-moving
engine support.
To set the tilt lock lever:
1. Tilt the motor all the way up using the power
trim and tilt.
2. Pull down the tilt lock lever 1 to hold the
motor in the fully raised position.
3. Lower the motor using the power trim and
tilt, until the motor is supported by the tilt
lock lever.
CAUTION
The motor is very heavy. When you tilt it man-
ually, you could injure your back or slip and
fall causing injury.
When you tilt the motor manually, ensure that
your grip and footing are secure and that you
are able to support the weight of the engine.
To release the lever, tilt the motor all the way up
using the power trim and tilt, and pull up the tilt
lock lever.
WARNING
If you do not take proper precautions when
tilting up the motor, fuel may leak out.
Disconnect the fuel line whenever you leave
the motor tilted up for a long period of time.
CAUTION
The remote Power Trim and Tilt switch will
work when the ignition switch is off. If some-
one activates the switch while you are moving
the tilt lock lever, your hand could be injured.
Keep all persons away from the remote Power
Trim and Tilt switch while you are moving the
tilt lock lever.
