0A-13 General Information:
Starter Motor
PTT Motor
Self-Diagnostic Code
Item Unit
Data
DF350AT
Max. continuous time of use Sec. 30
Motor output kW 1.4
Brush length
std. mm (in.) 12.3 (0.48)
Limit mm (in.) 7.0 (0.28)
Commutator undercut
std. mm (in.) 0.5 (0.02)
Limit mm (in.) 0.2 (0.01)
Commutator outside diameter
std. mm (in.) 29.4 (1.16)
Limit mm (in.) 28.4 (1.12)
Item Unit
Data
DF350AT
Brush length
std. mm (in.) 9.8 (0.39)
Limit mm (in.) 5.5 (0.22)
Commutator outside diameter
std. mm (in.) 22.0 (0.87)
Limit mm (in.) 21.0 (0.83)
Failed item Code Fail-safe system activating
MAP sensor 1 3 – 4 YES
Cylinder temp. sensor (PORT) 1 – 4 YES
IAT sensor 2 – 3 YES
Exhaust manifold temp. sensor 1 – 6 YES
Cylinder temp. sensor (STBD) 1 – 5 YES
Trim sensor 3 – 7 NO
Throttle position sensor 2 – 1 YES
Shift position sensor 1 – 2 NO
Rectifier/regulator (Over-charging) 1 – 1 NO
Fuel injector 4 – 3 NO
CKP sensor 4 – 2 NO
CMP sensor 2 – 4 NO
CMP sensor (VVTPORT) 2 – 6 YES
CMP sensor (VVTSTBD) 2 – 5 YES
Air intake system 2 – 2 YES
MAP sensor 2 (Pressure detect passage) 3 – 2 NO
Neutral switch 3 – 3 NO
VVT advance (STBD) 5 – 1 YES
VVT advance (PORT) 5 – 2 YES
Oil pressure switch 5 – 3 NO
Knock sensor 5 – 4 YES
Oil control valve (STBD) 6 – 1 NO
Oil control valve (PORT) 6 – 2 NO
ETV ECM 7 – 1 YES
ETV Motor 7 – 2 YES
ETV 7 – 3 YES
Sub BCM 7 – 4 YES
DBW system 7 – 5 NO
ESA ECM 8 – 1 NO
ESA motor 8 – 2 NO
ESA 8 – 3 NO
Keyless system authentication error 9 – 4 NO
Keyless system communication error 9 – 5 NO
Keyless system failure 9 – 6 NO
