Suzuki DR200SE User Manual

10-8 DR200SEK4/K5 (’04, ’05-MODELS)
ELECTRICAL
Unit: mm (in)
WATTAGE Unit: W
ITEM SPECIFICATION NOTE
Spark plug
Type
DENSO: X24ESR-U
NGK: CR8EA
Gap
0.6 – 0.7
(0.024 – 0.028)
Spark performance Over 8 mm (0.3) at 1 atm.
Signal coil resitance 100 – 140 Ω G – Bl
Ignition coil resistance
Primary 2 – 6 Ω
Terminal –
Terminal
Secondary 20 – 30 kΩ
Plug cap –
Terminal
Generator coil resistance Charging 0.1 – 1.5 Ω
Generator no-load voltage More than 60 V (AC) at 5 000 r/min
Generator Max. output 150 W at 5 000 r/min
Regulated voltage 13.0 – 16.0 V at 5 000 r/min
Starter relay resistance 2 – 6 Ω
Battery Type designation YTX7L-BS
Capacity 12 V 21.6 kC (6 Ah)/10 HR
Fuse size 20 A
ITEM SPECIFICATION
Headlight
HI 60
LO 55
Brake light/Taillight 21/5
Turn signal light 21
Speedometer light 3.4
Turn signal indicator light 3.4
High beam indicator light 1.7
Neutral indicator light 3.4

Suzuki DR200SE Specifications

General

Bore x Stroke	66.0 mm x 58.2 mm
Compression Ratio	9.4:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Drum
Engine Type	4-stroke, air-cooled, single-cylinder
Fuel System	MIKUNI BST31SS, single
Front Brakes	Single disc
Fuel Tank Capacity	13.0 L (3.4 US gal.)
Overall Width	805 mm (31.7 in)
Wheelbase	1, 405 mm (55.3 in.)
Ground Clearance	260 mm (10.2 in)
Curb Weight	126 kg (278 lbs)
