10-10 DR200SEK4/K5 (’04, ’05-MODELS)
SUSPENSION
Unit: mm (in)
TIRE PRESSUER
FUEL + OIL
ITEM STANDARD LIMIT NOTE
Front fork stroke 205
(8.1)
—
Front fork spring free length
—
561
(22.1)
Front fork oil level 179.5
(7.07)
—
Rear shock absorber spring
pre-set length
231
(9.1)
—
Rear wheel travel 205
(8.1)
—
Swingarm pivot shaft runout
—
0.6
(0.02)
COLD INFLATION
TIRE PRESSURE
SOLO RIDING DUAL RIDING
kPa kgf/cm
2
psi kPa kgf/cm
2
psi
FRONT 150 1.50 22 150 1.50 22
REAR 175 1.75 25 200 2.00 29
ITEM SPECIFICATION NOTE
Fuel type Use only unleaded gasoline of at least 87 pump
octane (R/2+M/2) or 91 octane or higher rated by
the research method. Gasoline containing MTBE
(Methyl Tertiary Butyl Ether), less than 10% etha-
nol, or less than 5% methanol with appropriate
cosolvents and corrosion inhibitor is permissible.
Fuel tank including reserve 13.0 L
(3.4/2.9 US/lmp qt)
E-03, 28
12.5 L
(3.3/2.7 US/lmp qt)
E-33
reserve
2.5 L
(0.7/0.5 US/lmp qt)
Engine oil type SAE 10W-40, API SF or SG
Engine oil capacity
Change
850 ml
(0.90/0.75 US/lmp qt)
Filter change
950 ml
(1.00/0.84 US/lmp qt)
Overhaul
1 100 ml
(1.2/1.0 US/lmp qt)
Front fork oil type Fork oil #10
Front fork oil capacity (each leg) 309 ml
(10.4/10.9 US/lmp oz)
Brake fluid type DOT 4

Suzuki DR200SE Specifications

General

Bore x Stroke	66.0 mm x 58.2 mm
Compression Ratio	9.4:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Drum
Engine Type	4-stroke, air-cooled, single-cylinder
Fuel System	MIKUNI BST31SS, single
Front Brakes	Single disc
Fuel Tank Capacity	13.0 L (3.4 US gal.)
Overall Width	805 mm (31.7 in)
Wheelbase	1, 405 mm (55.3 in.)
Ground Clearance	260 mm (10.2 in)
Curb Weight	126 kg (278 lbs)
