7-30
INSPECTION AND MAINTENANCE
60MK0-14E
80JM071
3) Open the fender cover. Disconnect the
coupler with pushing the lock release.
Turn the bulb holder counterclockwise
and remove it.
Rear combination light
(tail, stop, turn signal, etc.)
60MH053
Remove the screw (1). Remove the combi-
nation light (2) by pulling it outside.
License plate light
Since special procedures are required, we
recommend you take your vehicle to your
SUZUKI dealer for bulb replacement.
High-mount stop light
80J100
To remove a high-mount stop light housing
the following procedure:
1) Open the tailgate, and remove the nuts
(1) as shown in the illustration.
EXAMPLE
(1)
(1)
(2)
(1)
EXAMPLE
To Next Page
