7
D1
D1
D2
D3
D4
D5
D7
D6
A. The HP-275e includes 3 boxes;
The Piano, The Stand and The
Bench. Make sure you have all 3.
Unpacking and assembly should
take place on a soft surface such
ast carpeting or a furniture blanket
to protect the fi ne fi nish.
B. Open the Stand box fi rst and
remove the foam end blocks,
accessories and assembly parts.
C. The feet for the stand are stored
inside the 2 foam blocks in the center of
the stand box. Cut the tape and remove
them from the foam blocks and set aside.
D. Unpack the assembly parts.
You should have:
1. 2 Stand Feet wrapped in protective fi lm
2. 1 Phillips Screwdriver
3. 8 Large cover caps
4. 4 Small covers caps
5. 4 Cam Locks
6. 2 Paired speaker connection wires
7. 1 Power cord
8. 1 Instruction Manual
E. Using 2 people, lift the stand out of
the box and place it on a soft surface
upside down. Remove the protective
outer packing materials. Leave the clear,
thin protective fi lm in place for now.
1. Unpacking
ASSEMBLY
