Suzuki SMD9 User Manual

NAME
OUTLINE
Q'TY
DESCRIPTION/CODE №
ＰＡＣＫＩＮＧ ＬＩＳＴ
SMD9-E
1/1
NAME
OUTLINE
Q'TY
DESCRIPTION/CODE №
ユニット
UNIT
ﾏﾙﾁﾌｧﾝｸｼｮﾝﾃﾞｨｽﾌﾟﾚｲ
DISPLAY COMP MULTI 9
1
34910-98L10
付属品
ACCESSORIES
ﾉﾌﾞ(ﾎﾞﾙﾄ)
KNOB TOP MOUNT BRACKET
2
20-032-1062-1
34936-98L00
ﾊﾝｶﾞｰ
BRACKET TOP MOUNT 9
1
34933-98L10
ﾌｨﾙﾀｰｸﾘｰﾅｰ
CLEANER DISPLAY
1
34938-98L00
工事材料
INSTALLATION MATERIALS
Fﾏｳﾝﾄﾈｼﾞ
SCREW FLUSH MOUNT
4
K10LC3005AV
34920-98L00
Fﾏｳﾝﾄﾊﾟｯｷﾝ
GASKET FLUSH MOUNT 9
1
HGB15AX
31914-98L10
ｹﾞｰﾄｳｪｲ
GATEWAY
1
34923-96L00
1
FRU-2W-FU-01A
36663-88L20
CABLE POWER SUPPLY
1
CBC0FS0810
36663-98L00
図書 DOCUMENT
ﾌﾗｯｼｭﾏｳﾝﾄ型紙
SHEET FLUSH MOUNT
1
C42-01805-*
34915-98L00
操作上の注意
GUIDE SAFETY
INSTALLATION
1
E42-01804-*
34919-98L00
操作要領書(多言)
GUIDE OPERATION
1
MLG-45040-*
34918-98L00
装備要領書(英)
MANUAL INSTALLATION
1
IME-45040-*
34917-98L00
ﾜｲﾔ,2ｴｸｽﾃﾝｼｮﾝ(NMEA)
WIRE 2 EXTENSION
1
36662-88L10
ｺﾈｸﾀ BRANCH(NMEA)
CONNECTOR BRANCH
3
CBC0FS0810
36664-88L00
ﾕﾆｯﾄ,ﾚｼﾞｽﾀﾋ-ﾒｲﾙ(NMEA)
UNIT RESISTOR FEMALE
1
VTATM4.8X22TCCINX
36665-88L00
ﾀｯﾋﾟﾝﾈｼﾞ
SCREW BRACKET MOUNT
4
VTATM4.8X22TCCINX
34920-98L10
ﾕﾆｯﾄ,ﾚｼﾞｽﾀﾒ-ﾙ(NMEA)
UNIT RESISTOR MALE
1
VTATM4.8X22TCCINX
36665-88L10
ｹｰﾌﾞﾙ(ｸﾐﾋﾝ)
ﾊ-ﾈｽｱｯｼ,ﾈｯﾄﾜ-ｸﾊﾟﾜ-
HARNESS ASSY
NETWORK POWER
(KIT ONLY)
(KIT ONLY)
(KIT ONLY)
(KIT ONLY)
(KIT ONLY)
L=0.6M
L=1.5M
(KIT ONLY)
SMD9 ASSY P/No. 34900-98L10
SMD9 KIT
P/No. 34901-98L10
19BL-X-9852-2
19BL-X-9852
SMD9-E
A-2
HBS52BX
MINUCLOTH-GREY
