80
MIDI IMPLEMENTATION CHART
Function Transmitted Recognized Remark
Basic Channel 1 CH 1-16 CH
Channel changed 1-16 CH 1-16 CH
Default Mode 3 3
Note Number 9-120 0-127
Velocity: Note On ==
Velocity: Note Off X =
Pitch Bender ==
Control Change: 0 = X Variation page
1 X X Modulation
5 X X Portamento value
7, 10 ==Volume, Pan
11 X = Expression
64, 66, 67 ==Sustain, Sostenuto, Soft Pedal
65 X X Portamento yes/no
80, 81 ==Reverb, Chorus program
91 ==Reverb, Chorus send level
98, 99 X X NRPNL, NRPHH
100 ,101 X X RPNL, RPNH
121 ==Reset all controllers
123 ==All notes off
Program Change 0-127 0-127
System Exclusive X X
Sys. Common: Song Select X X
Sys. Common: Song Position X X
System: Clock X X
Real Time: Commands X X
Mode 1: OMNI ON, POLY
Mode 2: OMNI ON, MONO
Mode 3: OMNI OFF, POLY
Mode 4: OMNI OFF, MONO
MIDI IMPLEMENTATION CHART
