Suzuki VITARA series User Manual

2-154
BEFORE DRIVING
Automatic light operation
(if equipped)
61MM0A074
53SB2043
(3)
(4)
(2)
(1)
EXAMPLE
(5)
Your vehicle’s lighting system is controlled by two main systems: the lighting switch and
the auto-on headlight system (when the lighting switch is in “AUTO” position).
The two systems work together to operate your lights as shown in the following chart:
ON: Lights ON
LIGHT: When it is light around the light sensor (5).
DARK: When it is dark around the light sensor (5).
Lighting
switch posi-
tion
Main lights to be
operated
Ignition mode
“LOCK” (OFF)
or “ACC”
Ignition mode “ON”
LIGHT DARK LIGHT DARK
(1) OFF
Position lights,
Tail l ig h ts
––––
Headlights ––––
(2) AUTO
Position lights,
Tail l ig h ts
–––ON
Headlights –––ON
(3)
Position lights,
Tail l ig h ts
ON ON ON ON
Headlights ––––
(4)
Position lights,
Tail l ig h ts
ON ON ON ON
Headlights ON ON ON ON
