Suzuki VITARA series User Manual

7-57
INSPECTION AND MAINTENANCE
(For K14D engine model)
53SB60706
1) Loosen the hose band (1) and pull the
duct (2).
53SB60707
2) Unclamp the side clamps (3) and
remove the element from the air
cleaner case. If it appears to be dirty,
replace it with a new one. Be careful
not to disconnect the hose (4).
3) Reinstall the air cleaner case and
clamp the side clamps securely.
74SB50701
4) Align the duct with the marking (5) and
insert.
5) Tighten the hose band until the duct
does not come out.
6) After installing the duct, rock it back and
forth to ensure that it is installed
securely.
(2)
(1)
(3)
(4)
NOTICE
Overtightening the hose band may
damage the duct. Do not tighten the
hose band too much.
(5)
