2. CONTROL LOCATION
MODEL: AW05W-6/AW05W1-6/AW05W-D/AW05W-S/AW05W-F
無車身號碼及引擎號碼標示處
Fuel tank cap
Light/Starter switch
Muffler
High& Low beam/Turn
signal/Passing/Horn Switch
Front light/
Position light
Main stand
Front brake level
Tail/Stop light
Fuses &C.D.I
Battery
Air Cleaner
Oil level
Front turn
signal light
Helmet hook
Storage box
Kick starter
pedal
Side stand
Ignition switch
Rear turn
signal light
Engine start
control switch
Rear brake
level
