Sym MAXSYM 400 User Manual

6
7. Parts Location
1. Windscreen
2. Headlights & position lights
3. Front turn indicators
4. Front brake calipers
5. Front brake discs
6. Coolant level inspection window
7. Coolant reserve tank
8. Side stand
9. Oil filter
10. V-belt case air cleaner
11. Oil drain bolt
12. Transmission oil drain bolt
13. Transmission oil filler bolt
14. Engine air cleaner
15. Rear shock absorbers
16. Seat open lock
17. Tail/brake lights
18. Fuel tank cap
MAXSYM 400 (LZ40W1-EU)
1
3
2
4
6 7
8
9
13
14
16
17
5
10
11
12
15
18
