SystemAir SAVE VSR 500 Installation Guide

InstallationGuideSAVEVSR
300/500Ceilingmountingkit
2(6)
Warnings
Warning
•Bewareofsharpedgesduringmountingandmaintenance.Useprotectivegloves.
•Considertheunitweightwhenmounting!
•Thisproductmustonlybeoperatedbyapersonwhichhassuitableknowledgeoreducationwithinthiseldorcarried
outwiththesupervisionofasuitablyqualiedperson.
PossibleInstallationpositions
A.Uprightinstallationontheoor.Leftandrightconnectionsarepossible.
Theenclosedselfadhesivevibrationdampersmustbeused.
B.Ceilinginstallation.Leftandrightconnectionsarepossible.
Aceilingmountingkitisrequired.Notdeliveredwiththeunit.Needstobeorderedseparately.
C.WallinstallationisNOTallowed.UpsidedowninstallationisNOTallowed.
Note:
Theunitmaynotbeinstalledwiththeelectricalconnectionboxfacingdownwardduetothefactthattheheatfrom
there-heaterisrisingintheunit!
SystemairUABLinųst.101,LT–20174Ukmergė,LITHUANIA
Phone:+37034060165Fax:+37034060166209852-en-vA003

SystemAir SAVE VSR 500 Specifications

General

Supply voltage	230 V
Phase	1~
Frequency	50 Hz
Heat exchanger type	Counterflow
Filter class extract air	ePM10 50% (M5)
Operating temperature	-20°C to +40°C
