8.3Installation
1
Findanappropriateplacetoinstallthecontrolpanel.Maximumlengthbetweencontrolpaneland
unitis100m.
2
Ifneeded,drilltwoholesinthewalltohangthecontrolpanel(centertocenter:60mm)(pos.1,gure13).
Fig.13Controlpanelwireconnections
PositionDescription
1Mountingholes
2
Connectionblock
3
Connectiontobrowncable
4
Connectiontoyellowcable
5
Connectiontowhitecable
6
Connectiontoblackcable
TA450-4500Installationinstructions
132615
25
