3Productdescription
Fig.1Internalcomponents
Pos.Description
AFilter,supplyair
BFan,supplyair
C
Heater,ElectricalorWater
D
Connectionbox(HWunits)
E
Connectionbox(ELunits)
FDuctconnection,inlet
G
Ductconnection,outlet
3.1Fan
Thefanisadirectdrivenplugfanwithexternalrotormotor.Thefaniscontrolledintwospeedswitha
built-intransformerandiseasytoreachforcleaningandinspection.Themotorbearingsarelifetime
lubricatedandmaintenancefree.
3.2Supplyairlter
ThelterisofbagltertypewithlterqualityM5.Thelterneedtobereplacedwhenpolluted.Filter
monitoringisdoneviaabuilt-intimer.Newltercanbeacquiredfromyourinstallerorwholesaler.
3.3Temperaturesensor
InTAthesupplyairsensorisdeliveredwiththeunitandistobeinstalledinthesupplyairductexternally
fromtheunit.SeeInstallationinstructionsformoredetailedinformation.
TA450-4500
OperationandMaintenanceInstructions
132616
2
SystemairSverigeAB
