SystemAir Topvex TR800 User Manual

Topvex TR800, TR1300, TR1800, TR4000
Operation and Maintenance Instructions
Systemair Inc.
12
8
To end Wizard press OK. Using the UP/DOWN
arrow buttons to select YES. Press OK to conrm
followed by the DOWN arrow button.
End Wizard
No
After nishing the setup the menu system for “Operator level” will be available.
See menu overviews below that display the available menus in the Operator level followed by the “Service
level” manual.
To enter Service level use code 2222 in the “Access rights” menu. For operator level use code 1111.
Note:
To perform more advanced settings please see the enclosed CD which contains the Corrigo E -
manual.
4.3 Menu Overview Operator/Service Level
The menu overview below shows both the Operator and Service level. The overview of the parts unique to
the Service level in the table below are marked with grey background color. To logon to the Service level
use code 2222 under Access rights.
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
TR 800 EL ow
2010-03-15 9:00
System:Stopped
Sp:18.0 Act: °F
Start screen headline
Can be set to 5 different layouts
(Changeable at “system level”
under the conguration
menu).
→ Running mode → Running mode Running mode
Auto
Set running mode to Auto, On
or Off
Running time
SAF: 0.0 h
EAF: 0.0 h
Shows the time in hours that
motors have been operating
SAF = Supply air fan
EAF = Exhaust air fan
→ Selected
function
Control
function
Extract air
control
Fan control
Flow control
Shows type of air temperature
control the unit is congured for
Shows type of fan speed control
the unit is congured for
Heating: Water
Exchanger:
Rot. Excha
Cooling: Water
Shows type of heating selected
Shows type of exchanger
selected
Shows type of cooling selected
Table 6: Operator and Service Level
