Page #12 background imageLoading...
Page #12 background image
EN
12
English
Using more of your TV
2.
Press
/
to select a subtitle type and press
OK
to conrm. You can select
Hearing impaired
to
display the hearing impaired subtitles with your
selected language.
3.
Press
EXIT
or to close the menu.
Using Teletext
Selecting decoding page language
1.
Press
on the remote control, select
Channel >
Teletext > Decoding page language
and press
OK/
to enter.
2.
Press
/
to select a proper type of language
in which Teletext will display and press
OK
to
conrm.
3.
Press
EXIT
or to close the menu.
Digital Teletext language
On digital TV channels, depending on the
broadcaster, you may be able to enjoy a service with
multiple initial Teletext pages in different languages.
This function allows you to select an available
language as primary language, which relates to
different initial Teletext pages.
1.
Press
on the remote control, select
Channel >
Teletext > Digital teletext language
and press
OK/
to enter.
2.
Press
/
to select a language and press
OK
to
conrm.
3.
Press
EXIT
or to close the menu.
Networked waking up
This function allows you to turn on your TV from
standby mode via a network. To use this function,
please make sure:
1.
Your TV is connected to an effective home
network;
2.
The desired controller, such as a smartphone, is
connected to the same network as your TV;
3.
An App which supports networked waking up
function, has been installed into the controller;
4. Networked standby
is set to
On
in the
Network
menu.
When the TV is in networked standby mode, you can
use the App to wake up the TV remotely.
T-Link
Use this function to search for CEC devices connected
to the HDMI sockets in your TV and enable one-touch
play and one-touch standby between CEC devices.
Enabling or disabling T-Link
1.
Press
on the remote control, select
System >
T-Link
and press
OK/
to enter.
2.
Press
/
to select
T-Link
and press
OK/
to
enter.
3.
Press
/
to select
On
or
Off
and press
OK
to
conrm.
4.
Press
EXIT
or
to close the menu.
Using Auto Power On
Enables the TV to automatically power on when you
power on a CEC device (e.g. DVD) with the device’s
remote. Select
On
to enable this function.
Using Auto Standby
Enables all CEC devices to automatically go to the
standby mode when you turn off the TV with the TV
remote. Select
On
to enable this function.
Note: The CEC functions depend on the devices
connected and it is possible that some
devices may not interoperate correctly when
connected to this TV. The user manual or
the manufacturer of the problematic devices
should be consulted for further information.
HbbTV
HbbTV (Hybrid broadcast broadband TV) is a service
offered by certain broadcasters and available only on
some digital TV channels. HbbTV delivers interactive
television over broadband Internet. These interactive
features are added to and enrich the normal digital
programmes, and include services such as digital
teletext, electronic programme guide, games, voting,
specic information related to the current programme,
interactive advertising, information magazines, catch-
up TV, etc.
To use HbbTV please ensure your TV is connected to
Internet and HbbTV is switched on.
Notes:
-
HbbTV services are broadcast- or country-
dependent and may be unavailable in your area.
-
You cannot download les to your TV with
HbbTV function.
-
Application provider or broadcasting related
conditions may cause an HbbTV application to
be unavailable momentarily.
-
To access HbbTV applications you must connect
your TV to the Internet via a broadband link.
HbbTV applications may not work correctly in
case of network related issues.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 40ES560 and is the answer not in the manual?

TCL 40ES560 Specifications

General IconGeneral
Screen shapeFlat
Response time30 ms
Display diagonal40 \
Display brightness270 cd/m²
Display technologyLCD
Native aspect ratio16:9
Native refresh rate60 Hz
Peak luminance ratio76 %
LED backlighting typeDirect-LED
Supported video modes1080p
Viewable size diagonal1000 mm
Contrast ratio (typical)-
Display diagonal (metric)101.6 cm
Motion interpolation technologyPPI (Picture Performance Index) 400
Dynamic contrast ratio marketing nameMega Contrast
HDMI version1.4
HDMI Quick SwitchYes
RF connector typeF, IEC
USB 2.0 ports quantity1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, JPG, PNG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, OGM, TS, VP9, WMV
Picture processing technologyTCL Pure Image Ultra
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Video appsNetflix
Smart modesGame, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version9.0
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version1.5
Audio decodersDolby Digital, Dolby Digital Plus
RMS rated power16 W
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profilesA2DP, HID
Product colorBlack
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface100 x 100 mm
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Remote control typeRC802N1
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (max)75 W
Power consumption (standby)0.29 W
Power consumption (typical)46 W
Package depth130 mm
Package width1040 mm
Package height634 mm
Package weight8600 g
CertificationCE
Truck type100 cbm
Pallet width800 mm
Pallet height1420 mm
Pallet length1200 mm
Pallet weight116660 g
Quantity per truck792 pc(s)
Quantity per pallet12 pc(s)
Number of pallets per truck66 pc(s)
Maximum number of stacking cartons4 pc(s)
Weight and Dimensions IconWeight and Dimensions
Stand width770 mm
Depth (with stand)186 mm
Height (with stand)575 mm
Depth (without stand)75 mm
Width (without stand)905 mm
Height (without stand)524 mm
Weight (without stand)6400 g
