Page #10 background image
EN
10
English
Chapter 4 - Using more of your TV
Installing channels
This section describes how to search and store
channels automatically. This may be done in any of
the cases below:
- you have skipped the channel installation step in the
initial setup;
- you are prompted that there are no channels in TV
mode;
- you want to update your channels.
1.
In TV mode, press
on the remote control and
select
Channel > Channel scan
. Press
OK/
to
enter.
2.
The TV installs and arranges channels according
to your country or region. Press
/
to select
Country/Region
, and press
OK/
to enter. Enter
the default password 1234 or your own password
in case you have changed the password in the
System
menu. Press
/
to select your country
or region and press
OK
to conrm.
3.
Press
/
to select
Automatic search
and press
OK/
to enter.
4.
Press
/
to select
Tuner mode
and press
/
to select
Cable
,
Antenna
or
Satellite
.
(Note: Satellite option is available only in selected
models.)
5.
Press
/
to select other options to congure.
6.
After conguration is completed, press
to select
Search
and press
OK
to start scanning channels.
7.
The channel search may take a few minutes. After
the automatic search, channels are arranged in a
preset order. If you wish to hide or move channels,
press
on the remote control, select
Channel >
Channel organizer
and press
OK/
to enter.
Common interface
Encrypted digital TV channels can be decoded with a
common interface module and a card provided by a
digital TV service operator.
The common interface module may enable several
digital services, depending on the operator and
services you choose (for example, pay TV). Contact
your digital TV service operator for more information
about services and terms.
Using the common interface module
WARNING: Switch off your TV before inserting a
common interface module. Be sure to follow the
instructions described below. Wrong insertion of
a common interface module may damage both the
module and your TV.
1.
Following the directions printed on the common
interface module, gently insert the module into the
common interface slot on the TV.
2.
Push the module in as far as it will go.
3.
Turn on the TV and wait for the common interface
function to be activated. This may take several
minutes.
Note: Do not remove the common interface
module from the slot. Removing the module
will deactivate the digital services.
Accessing common interface services
After inserting and activating the common interface
module, press
on the remote control, select
Channel > Common interface
and press
OK/
to
enter.
This menu option is only available if the common
interface module is correctly inserted and activated.
On-screen applications and content are provided by
your digital TV service operator.
Using subtitles
You can enable subtitles for each TV channel.
Subtitles are broadcast via Teletext or DVB-T/DVB-C/
DVB-S/DVB-T2/DVB-S2 digital broadcasts. With
digital broadcasts, you have the additional option of
selecting a preferred subtitle language.
Turning on/off subtitles
1.
Press
on the remote control, select
Channel >
Subtitle
and press
OK/
to enter.
2.
Select the
Subtitle
option, and press
OK
to toggle
between on or off.
3.
Press
EXIT
or to close the menu.
Enabling subtitle languages on digital TV
channels
1.
Press
on the remote control, select
Channel >
Subtitle > Digital subtitle language 1st
and
press
OK/
to enter.
2.
Press
/
to select a subtitle language as your
preferred language and press
OK
to conrm.
3.
Press
/
to select
Digital subtitle language
2nd
and press
OK/
to enter.
4.
Press
/
to select a secondary subtitle language
and press
OK
to conrm.
5.
Press
EXIT
or to close the menu.
Shortcut operation:
Press
SUBT.
on the remote
control to directly select a subtitle language available
for the selected digital TV programme.
Selecting a subtitle type on digital TV
channels
1.
Press
on the remote control, select
Channel >
Subtitle > Subtitle type
and press
OK/
to enter.
2.
Press
/
to select a subtitle type and press
OK
to conrm. You can select
Hearing impaired
to

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 40S5200 and is the answer not in the manual?

TCL 40S5200 Specifications

General IconGeneral
Screen shapeFlat
Response time30 ms
Display diagonal40 \
Progressive scanYes
Anti-glare screenNo
Display brightness270 cd/m²
Display technologyLCD
Native aspect ratio16:9
Native refresh rate60 Hz
Peak luminance ratio76 %
LED backlighting typeDirect-LED
Supported video modes1080p
Viewable size diagonal1000 mm
Viewing angle, vertical- °
Contrast ratio (typical)-
Display diagonal (metric)101.6 cm
Screen format adjustments4:3, 16:9
Supported graphics resolutions1920 x 1080 (HD 1080)
Motion interpolation technologyPPI (Picture Performance Index) 400
Dynamic contrast ratio marketing nameMega Contrast
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Channels quantity- channels
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modesGame, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version11
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version1.5
Audio decodersDolby Digital, Dolby Digital Plus
RMS rated power16 W
Number of speakers2
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version5.0
Bluetooth profilesA2DP, HID
Product colorBlack
Mercury content0 mg
Panel mounting interface100 x 100 mm
Processor cores4
Audio formats supportedWMA, MP3
Image formats supportedBMP, JPG, PNG
Video formats supportedAVI, WMV, MP4, MPG, TS, MKV, OGM
Picture processing technologyTCL Pure Image Ultra
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
HDMI version1.4
RF connector typeF, IEC
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Programming period8 day(s)
Number of OSD languages39
Firmware upgradeable viaNetwork, USB
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (max)75 W
Power consumption (standby)0.32 W
Cables includedAC
Remote control typeRC802NU1
Package typeBox
Package depth130 mm
Package width1046 mm
Package height640 mm
Package volume87027.2 cm³
Package weight8680 g
Truck type87 cbm
Pallet width800 mm
Pallet weight116660 g
Pallet net height1420 mm
Pallet net length1200 mm
Quantity per truck396 pc(s)
Quantity per pallet12 pc(s)
Quantity per pallet layer6 pc(s)
Number of layers per pallet2 pc(s)
Number of pallets per truck33 pc(s)
Quantity per master (outer) case1 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292517144
Maximum number of stacking cartons4 pc(s)
Repairability index6.3
Battery typeAAA
Battery weight15 g
Doesn't containMercury
Country of originPoland
Battery technologyAlkaline
CertificationCE
Weight and Dimensions IconWeight and Dimensions
Stand width770 mm
Depth (with stand)186 mm
Width (with stand)905 mm
Height (with stand)575 mm
Weight (with stand)6420 g
Depth (without stand)75 mm
Height (without stand)524 mm
Weight (without stand)6360 g
